HyperMesh
Mechanical · CAE Pre-processing
Altair HyperMesh — industry-leading FEA pre-processing.
Course Quick Info
| Duration | 1 – 1.5 Months |
|---|---|
| Mode | Classroom at KPHB + Online Available |
| Certificate | Industry-recognized completion certificate |
| Placement | Placement Assistance — Automotive CAE & Aerospace Structural Teams |
| Who Should Join | Mechanical engineering graduates targeting CAE/FEA pre-processing roles — especially automotive crash analysis, structural durability and aerospace teams |
Why HyperMesh?
HyperMesh (by Altair) is a leading FEA pre-processing software used to convert CAD geometry into high-quality finite element meshes for use in solvers like ANSYS, Nastran, Abaqus and LS-DYNA. It is especially important in automotive crash/safety analysis and aerospace structural analysis, where mesh quality directly affects simulation accuracy.
Curriculum
Course Syllabus
8 modules
- Importing CAD geometry and cleanup for meshing
- Bar/beam elements and shell meshing techniques
- Tetra and hexa meshing for solid components
- Element quality criteria, Jacobian, aspect ratio, and warpage
- Welds, bolts, RBEs, and contact definitions
- Applying loads and constraints for solver-ready models
- Exporting models to ANSYS, Nastran, Abaqus and LS-DYNA formats
- Full pre-processing of a real automotive/structural component for FEA
Career Opportunities
- ✓CAE Mesh Engineer
- ✓FEA Pre-Processing Engineer
- ✓Structural Analyst (Pre-Processing) at automotive OEMs and Tier-1 suppliers, aerospace structural analysis groups
Frequently Asked Questions
Not exactly — HyperMesh is primarily a pre-processing/meshing tool; the actual simulation is run in a solver such as ANSYS, Nastran, Abaqus or LS-DYNA, with HyperMesh preparing the mesh and model setup for that solver.
Poor mesh quality leads to inaccurate or unreliable simulation results, even if the solver settings are correct; that's why this course spends significant time on mesh quality checks and cleanup techniques.
Ready to start your career in HyperMesh?
Talk to Manju Ma'am, sit in on a live class, and decide for yourself.
